Slurry Plate Chamber Filtering Machine Press Filter

This filter press could be of automatic plate opening device and automatic water collector, which automatic open the plates one by one, automatic open and close the water collector.

  • Lead Time:

    according to the machine model and quant
  • Product Origin:

    china
  • Shipping Port:

    xiamen
  • Payment:

    T/T, LC at sight
  • Color:

    customized
  • MOQ:

    1
  • Product Details

Slurry Plate Chamber Filtering Machine Press Filter


Filter Press Characteristic:

  1. Strengthen polypropylene filter plates and flame are made through mold pressing.

  2. Adopt hydraulic pressing with the maximum pressure pressure of 25Mpa and automatic pressure maintaining by using electrical connecting pressure gauge.

  3.PLC control system, automatic open the plates one by one, open and close the water collector.



Filter Press Application:
Square filter plates are widely used in Food, Chemical, Dyeing, Leather, Mining (Aluminium, Bauxite, Copper, Iron) and Electroplate.


Filter Press Working:

The slurry is sent by slurry pump to chambers which formed by filter plates. Then filtrating media (filter cloth) separates solid and liquid. After the filtration finished, stopping the feeding, releasing the slurry pressure, press the returning button, shifting the plates automatically.

How Chamber Filter Press Work




Filter Press Technical Parameters:

Hydraulic Chamber Filter Press With Square Plates

Model



Filter

Area

(m2)

Inner

Size

(mm)

Plate

Thickness

(mm)

Motor

Power

(kw)

Plate

Number

(Pcs)

Filter

Capacity

(L)

Working

Pressure

In

Chamber

(Mpa)

External

Size

(mm)

L*W*H

Weight

(kg)

NX-630

16

630*630

50

1.5

26

200

≤1.0

2790*1020*1200

1320

20

32

250

3096*1020*1200

1400

25

40

313

3504*1020*1200

1540

NX-800

50

800*800

60

1.5

50

750

≤1.0

4794*1246*1325

3140

60

60

900

5404*1246*1325

3470

70

70

1050

6014*1246*1325

3950

NX-1000

50

1000*1000

60

3.0

30

750

≤1.0

3984*1500*1555

4590

60

36

900

4350*1500*1555

4800

70

42

1050

4716*1500*1555

5160

80

48

1200

5082*1500*1555

5440

Plates could be added or reduced according to customer's requirements.




Pre-sale service:
1.Your inquiry will be replied within 8 hours.
2.Help you to select suitable model

3. Spare parts are in stock


After-sale service:
1.Provide 12 months warranty period and you will have our technology support forever
2.Engineering available to offer the service to your machinery overseas
