Ceramic Sewage Sludge Mud Reciprocating Piston Pump

This ceramic sludge pump is one piston pump reciprocating working, it is suitable for long distance sludge transpotation.

  • Lead Time:

    according to machine model and quantity
  • Product Origin:

    china
  • Shipping Port:

    xiamen
  • Payment:

    T/T, LC at sight,
  • Color:

    customized
  • Inventory:

    20
  • MOQ:

    1
  • Product Details

Thick Slurry Transport Hydraulic Ceramic Plunger Pump


Ceramic Plunger Pump Characteristic:

1. Hydraulic driven, one ceramic pistons working up and down stably

2. The highest feeing pressure could be 2.5Mpa, the rate pressure is 2.0Mpa, the pressure could be adjusted.

3. Pistons are made of alumina ceramics,of great abrasion resistance and corrosion resistance.


Ceramic Plunger Pump Technical Parameters:


Model

Flux

(m3/h)

Pressure

Range

(Mpa)

Rated

Pressure

(Mpa)

Motor

Power

(kw)

Diameter

Suction And

Discharge

mm

YBS-85

1.5

0-2.5

2.0

4

Ø76

YBS-120

3.5

0-2.5

2.0

11

Ø76

YBS-140

5

0-2.5

2.0

11

Ø76

YBS-200

9.5

0-2.5

2.0

18.5

Ø89

YBS-250

15

0-2.5

2.0

22

Ø133

YBS-300

20

0-2.5

2.0

30

Ø133


Every kind thick slurry transportation, such as marble, granite, glass, ceramic, clay, kaolin, textile, and other kinds of wastewater.


Slip Pump Plunger Pump

Wastewater Plunger Pump
