Diaphragm Filter Press AdvantagesThe filter chamber of the diaphragm filter press is formed by staggered splicing of chamber plates and diaphragm plates, a solid filter plate and a diaphragm filter plate.The diaphragm plate of the diaphragm filter press has a diaphragm cavity on both sides. When the material is filtered, inject a certain pressure of gas (liquid) into the diaphragm cavity to make the diaphragm bulge and spin the filter cake in reverse to achieve the purpose of reducing the moisture content of the filter cake. When the press medium (such as compressed air) is passed through the back side of the diaphragm, these movable diaphragms will bulge toward the filter chamber, that is to say, the filter cake will be squeezed under high pressure again after the filtering process is over. The Nanxing chamber filter press is equipped with a membrane filter plate filtration process, and the moisture content of the filter cake can be 10-40% lower than that of ordinary filter plates. Can save a lot of follow-up costs. The filter part is composed of filter plates neatly arranged on the main beam and a filter medium sandwiched between the filter plates. Reinforced polypropylene filter plate is mainly made of high-quality polypropylene and pressed by our company’s unique formula. It has good mechanical properties, stable chemical properties, pressure resistance, heat resistance, corrosion resistance, light weight, flat and smooth surface, good sealing, and easy Features such as washing. At the beginning of filtration, the filter slurry is driven by the feed pump and enters each filter chamber through the feed port of the thrust plate. The filter slurry is separated from the solid and liquid by the pressure generated by the feed pump, due to the role of the filter medium (filter cloth) , Make the solid stay in the filter chamber to form a filter cake, and the filtrate is discharged from the water nozzle or the liquid outlet valve. If the filter cake needs to be washed, the washing water can be passed through the washing port on the thrust plate to wash the filter cake; if a filter cake with lower moisture content is required, compressed air can be passed through the washing port to pass through the filter cake layer and blow out Part of the water in the filter cake can be squeezed through the diaphragm to make the washing water less and the effect is better.

How to process mud sewage1. Concentration of sludge. The purpose of sludge thickening is to dehydrate sludge and reduce sludge volume, creating conditions for subsequent processing. Concentration and dehydration methods include gravity sedimentation concentration, floating concentration and other concentration methods.2. Sludge digestion. In order to reduce sludge amount, prevent environmental pollution and increase its utilization value, digestion treatment is generally required. Sludge digestion is the use of microbial metabolism to decompose the organic matter in the sludge into stable substances, remove odors, kill parasite eggs, and reduce the volume of sludge. The biogas produced in the digestion process is recycled.　3. Sludge dewatering and sludge drying. After the sludge is concentrated and digested, its water content is still about 96%, and the volume is large, which is not convenient for transportation and use. It needs further dehydration and drying treatment. The main methods are natural evaporation and mechanical dehydration.4. Sludge incineration. After the sludge is dried. The water content is still 10%-15%, and the volume is still large. The water and organic impurities in the sludge can be completely removed by incineration, and kill pathogenic microorganisms. Some sludge contains toxic substances and is not suitable for agricultural fertilizers, or it is difficult to use sludge for other reasons, in order to prevent pollution, Incineration method is also used. The device for burning sludge is an incinerator.　5. Final treatment of sludge. When the sludge contains toxic substances such as heavy metal ions, it must be finished, buried deep or thrown into the ocean.　In fact, in the above steps, if there is a mud-water separation equipment (horizontal plate filter press & Slurry Sewage Pump from our Nanxing company, it will save time. To purchase or consult solid liquid separation equipment, please follow the official website of Fujian Nanxing Environmental Protection Equipment Co., Ltd. (www.nxfilterpres.com) and contact us for consultation

Precautions for Filter Press Safe Operation10. Wash the filter press filter cloth as required to increase the water permeability of the filter cloth and improve the efficiency of filter press. 11. Before stopping, stop feeding and unload all the materials in the filter press before stopping. It is strictly forbidden to stop with materials. 12. After the board frame is loosened, after the slag is finished under one board, use a plastic spatula to clean the remaining waste, and then clean the other board. It is strictly forbidden not to clean the residue. 13. After unloading the board slag, when cleaning the board frame and filter cloth, ensure that the holes are unblocked, and do not allow the residue to stick to the sealing surface or the feeding channel. 14. When installing the board, when the board frame moves on the main beam, it must not be collided or beaten. The force should be evenly applied to prevent damage to the handle and damage to the sealing surface. 15. The damaged filter cloth should be replaced in time. When installing the filter cloth, it must be flat and not allowed to be folded to prevent damage and material leakage when the plate frame is compressed. 16. When storing the disassembled board and frame, it should be laid flat to prevent warping and deformation. 17. The sealing surface of the recessed filter plate must be clean and free of wrinkles. The filter plate should be vertical and tidy with the main beam, and must not be leaning forward and backward, otherwise the pressing action must not be started. 18. It is strictly forbidden to extend the head and limbs into the filter plate during the process of unloading the slag. 19. Leaking muddy water and damaged filter cloths should be replaced in time, washed, dried, stacked neatly, and treated in a unified manner. 20. Keep the filter cloth free from entrainment and wrinkles. Keep the surface of the pp chamber filter plate flat and smooth. The handle of the filter plate should be handled gently. When pressing, ensure that the filter plate discharges neatly and does not deviate from the compression centerline.

Filter Press Safe Operation1. During the filter press working, the operator shall not put his feet, hands, or head into the filter plate of the filter press or observe the belt conveyor or the middle groove from the gap between the opened filter plate. It is forbidden to put tools on the hook frame and on the handle of the filter plate. 2. Do not press the switch when there are people on the frame, machine top, or beam. 3. The hydraulic part of the filter press machine must be equipped with an electric contact pressure gauge. 4. It is forbidden to wear high heels and work barefoot. It is strictly forbidden to put your head and hands into the filter plate during the unloading process. 5. It is forbidden to operate the buttons with gloves, and only use wooden shovel (bamboo chips) for unloading. 6. Before work, check whether the operating buttons are flexible and reliable, and whether the unloader is synchronized. 7. Before work, pay attention to check whether there is any debris between the filter press plates and whether the filter cloth is wrinkled, and clean up in time after discovery. 8. During the horizontal filter press process, observe the outflow of the filtrate. When it is found to be damaged, write down the number and repair or replace the filter cloth in time. 9. Pay attention to check whether the filter plate is deformed or broken, and replace it in time when it is found. When replacing the filter plate, remove the filtrate tap first. 10. Wash the filter cloth as required to increase the water permeability of the filter cloth and improve the efficiency of filter press.

1. The filter cloth (filter press parts) is placed incorrectly. There are many reasons why the filter chambers of clay filter press cannot be sealed, we need start with a simple, around the filter room, check to see if the filter cloth has wrinkles or broken edges of the filter cloth. Because the structure of the filter chamber is formed by filter plates and the filter cloth. Under high pressure, normally the filter plates are not easy to break, but filter cloth  easily wrinkles or incompleteness, which will easily cause gaps between the filter plates.2. Insufficient pressure of press filter machine. Thefilter plateand filter cloth must be under high pressure so that they could form a closed filter chamber. When this pressure is insufficient, when it is lower than the  industrial filter press slurry pressure, the slurry will leak through the gap.3. Deformation or damage of the filter plate. When the edge of the filter plate is damaged, even slightly protrusion, the filter chambers it formed will have gap which will also lead to slurry leak which will be relatively large, what is more, it may even be ejected.

Why Filter Plates Broken1. The filter press is damaged, causing uneven force on the filter plate, and the filter press its pressure crushes the filter plate;2. It is caused by the slurry .The slurry contains hard particles which will cause the membrane filter plate easily damaged.3. The feed hole is blocked. Several filter plates near the feed inlet are damaged, which can be preliminary judged to be blocked at the feed inlet. If the slurry concentration is too large, or the cleaning is not timely, the feed hole will be blocked.4. The feed pressure is too high.When back pressure occurs, or the pressure gauge display exceeds the pressure specified on the nameplate, Indicates that the feed pressure is high. The solution is adjusting the pressure controller system.5. The material concentration is high and the fluidity is too poor, the solution is reducing the material concentration and improve slurry mobility.6. The feed temperature is too high.Understand the temperature of the slurry firstly, when the temperature of the filtered slurry exceeds the filter plate equipped. When using the temperature, you should explain the reason to the customer, and replace the appropriate filter plate or take the temperature of cooling slurry before filtering;7. The filter cloth is damaged and the outlet hole is blocked.There are a few individual water holes and the filtrate is turbid, it can be judged that the filter cloth is damaged and the water holes. If there is no liquid, it can be judged that the liquid hole is blocked. The filter cloth should be replaced and the liquid outlet hole should be cleaned.

   How is membrane filter press work.   membrane filter press filtration chambers are formed by chamber filter plate and diaphragm filter plate. Diaphragm is the filter plate with a membrane cavity on both sides. The chamber filter plate and the diaphragm plate with the same shape are arranged at intervals to form a filter chamber of a certain volume.   After slurry filtration is finshed, a certain pressure of gas (liquid) is injected into the diaphragm cavity to make the diaphragm bulge and squeeze the filtered cakes to reduce its moisture.   When the membrane filter plates are feeded the compressed air or water, these inflatable diaphragms will bulge in the direction of the filter chamber to squeeze the filtered cakes after the first filtration finished.     After the filter press is equipped with the filtration process by the membrane filter plate, and the moisture of filtered cakes can be 10-40%, much lower than chamber filter plate, which saves great filtration costs.   The filter part is composed of filter plates, membrane plates and filter cloth arranged on the main beam.   Reinforced polypropylene filter plate is mainly made of high-quality polypropylene and pressed by our company's unique formula. It has good mechanical properties, stable chemical properties, pressure resistance, heat resistance, corrosion resistance, light weight, smooth surface, good sealing, and easy Features such as washing.   At the beginning of filtration, the filter slurry is transferred by the plunger mud pump and enters each filter chamber through the feed port of the thrust plate. The particles are separated from liquid by the pressure generated by the mud plunger pump. Through the filter cloth, the solid stay in the filter chamber to form a filter cake, and the liquid is discharged from the water nozzle or the liquid outlet valve.   If a filter cake with a lower moisture content is needed, the squeezing of the diaphragm can make the filtered cakes moisture less and the filtration effect will be better.

For hydraulic automatic filter presses and mechanical manual filter presses,the essential differences is the pressure source of the filter, which is mainly reflected in the provision of pressure force is different.The power of the manual filter press comes from the rotation of the motor, through the rotation of the motor to drive the gear, and then through the gear to make the screw connected with the pushing filter plate perform forward or retreat, to press, squeeze and pull back of the filter chamber.Hydraulic automatic filter press is a kind of intermittent pressure filter equipment, used for the solid-liquid separation of various suspensions, different from the mechanical filter press.The hydraulic automatic filter press works through the hydraulic system. It includes a hydraulic station, a hydraulic chamber and a controller point. The hydraulic oil is transmitted through the pumping of the hydraulic station, by the hydraulic pressure in the hydraulic station. The oil is sent into the pipe, and then the pipe sends the hydraulic oil separately through the controller, to the forward or backward chamber of the hydraulic system to press the piston back and forth, then the piston rod will transmit the power to the push or pull the filter plates.Essentially, the hydraulic automatic filter press is developed on the basis of the  mechanical manual filter press. The hydraulic automatic filter press is an integrated mechanical manual press, developing many advantages, such as the pressure provided by it has been significantly increased; full mechanization has completely changed the manual maintenance of the manual filter press; the alkali resistance, acid resistance and abrasion resistance have been significantly improved, and it is more adaptable harsh working environment; it can be applied to more industries.Hydraulic automatic filter press has good filtration efficiency and convenient use in petroleum, chemical, dye, metallurgy, pharmaceutical, food, paper, coal washing and various industries requiring solid-liquid separation(such as sewage treatment).Hydraulic automatic filter press realizes the automatic pressure holding, greatly increase the company’s labor and other costs.

Filter Plate Damage Reason and Solution　　Main reason:　　　　A) The mud is too thick or there are dry blocks left, causing the blockage of the feeding port, There are no other substances inside the filter plate, only the hydraulic system pressure existing, which extremely easy cause damage due to prolonged pressure.　　　　B) When the feed is insufficient or the feed contains inappropriate solid particles, it will also cause excessive force or damage to the filter press plate.　　　　C) If the outlet is blocked by solids or the feed valve or discharge valve is closed when starting, it will lead to be no place for pressure to release, pressure filter plate may cause damage.　　　　D) When the filter plate is not cleaned thoroughly, it may cause the medium to leak, as long as the medium leaks, small grooves will be punched out at the edge of the plate frame. If large amount of medium leakage, it will definitely cause the pressure reduce, water could not be filtered out, the mud will contains much water.　　Solution:　　　　A) Carefully use a nylon cleaning scraper to remove the mud from the feed inlet;　　　　B) After completing a filtration cycle, reduce the volume of the filter plate;　　　　C) Check carefully whether there is a problem with the filter cloth, and then check whether it is smooth. Checking whether the outlet is smooth or not, and clean the drain. open the corresponding pressure valve, and release pressure off.　　　　D) Carefully clean and repair the filter plate.

2021 National Holiday   Please be noted our following holiday arrangements for Fujian Nanxing Environmental Technolygy Co., Ltd staffs, customers, suppliers and any other relevant parties for 2021 National Festival, it starts from 30th September to 4th October.   If any urgent thing, please contact us by mobilephone, my mobile (wechat) is 0086-15905991249.   Best wishes to all chinese for a Happy National Day and an enjoyable break.

THE 21ST CHINA SHUITOU INTERNATIONAL STONE MACHINE FAIRExhibition time:December 12-December 15, 2020Opening and closing time:09:00-18:00Host address:Fujian-Quanzhou Shuitou International Stone Exhibition Centerorganizer:Fujian Provincial People's GovernmentIndustry: Stone Machine (including stone processing machines, tools and stone wastewater treatment).Our company also attends this fair, Chamber filter press and Hydraulic piston pump are widly used in stone wastewater treatment, both marble and granite are suitable.If you have any question or inquiry about stone sewage treatment, or you are urgent for water reclying in stone sewage treatment, welcome to our booth D 67, we are waiting for your visit!

China's Container Production ExpandingBecause of Covid-19, international logistics capacity decline greatly, the price of container shipping has skyrocketed. A few days ago,China’s Ministry of Commerce spokesperson Gao Feng said recently that the mismatch between supply and demand of capacity is the direct cause of the increase in freight rates. They will continue to work with relevant departments on the basis of preliminary work, promote the increase of transportation capacity, support the acceleration of container return transportation, improve operational efficiency, support container manufacturers to expand production capacity, and at the same time increase market supervision, strive to stabilize market prices, and provide strong logistics support for the stable development of foreign trade.In a word, In the short term, lack of boxes is still a problem.It also greatly effect our filter press, filter plates, ceramic piston pump and relative accessories export, it greatly increased our foreign customers' import cost, hope ocean freight could keep stable soon.
